Description:
-This key switch is an emergency switch button with a special mechanical key for emergency situations.
-19mm key switch lock with 2 keys, nice smooth action and easy to mount.
-Key is removable in both ON and OFF positions.
Specification:
Panel Material: 304 Stainless Steel
Rated Power: 4A 125V AC / 2A 250V AC
Type: DPST
Contacts Type: 2 NO, 2 NC, 2 COM
Cable Length: 20mm / 0.79"
Panel Size: 115 x 70mm / 4.53" x 2.76" (L*W)
Mounting Cut Hole: 19mm / 3/4"
Panel Mounting Hole Diameter: 4.5mm / 0.18"
Panel Mounting Hole Distance: 83mm / 3.27"
Package Content:
1 x Key Operated Switch
2 x Keys
2 x Mounting Screws
