| Series | 4-Port PCIe Gigabit Network Adapter Card |
| Item model number | ST1000SPEX43 |
| Hardware Platform | PC;Unix |
| Operating System | Windows 10 Windows 8 Windows 7 Linux Windows Server 2012 Windows Server 2003 Windows Server 2016 Windows Server 2019 |
| Product Dimensions | 5.4 x 4.7 x 0.7 inches |
| Item Dimensions LxWxH | 5.4 x 4.7 x 0.7 inches |
| Voltage | 240 Volts |
| Manufacturer | StarTech.com |
| ASIN | B015FTXD0Y |
| Is Discontinued By Manufacturer | No |
| Date First Available | October 9, 2015 |
This 4-port network card delivers powerful connectivity for your business, corporate or government office environment, with support for high-performance, 4-channel networking and a maximum throughput of up to 1000Mbps in each direction (2000 Mbps total). The network adapter card features the Realtek RTL8111G chipset, which is designed to deliver the performance and enhanced capabilities you need for reliable network connections to your server or computer.
This versatile quad-port network card is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking with four independent ports. Compatible with a broad range of operating systems, this cost-effective PCIe Gigabit NIC is suitable for many SMB and Enterprise applications such as virtualized environments that require multiple NICs (check your VM software for chipset compatibility).
Provides simultaneous access to multiple networks for desktop PC clients, servers, and workstations that have a limited number of PCI Express slots available.
Maximizes the number of RJ45 ports within a system or high-end workstations and servers.
Ideal for VM environments with multiple operating systems, requiring shared or dedicated NICs.
Provides redundant connectivity to ensure an uninterrupted network connection.
Look for StarTech Branded Packaging to ensure you are getting a genuine StarTech product.
1 - PCIe Gigabit network card - 4 port.
The StarTech ST1000SPEX43 4-port PCIe Gigabit network adapter card offers 4-channel networking and a maximum throughput of up to 1000 Mbps in each direction. It features the Realtek RTL8111G chipset for reliable network connections to your server or computer. This adapter supports full-duplex flow control, auto negotiation with next-page capacity, up to 9K jumbo frame, IEEE 802.1Q VLAN tagging, IEEE 802.1P layer 2 priority encoding, wake-on-LAN and remote wake-up. It is great for many SMB and enterprise applications such as virtualized environments that require multiple NICs. . Network adapter card offers simultaneous access to multiple networks for desktop PC clients, servers and workstations. Dimensions: 0.7"H x 4.7"W x 5.4"D. Comes in yellow color. Interface/ports: one PCI express x four male, four RJ-45 female (external). Data transfer rate: 2000 Mbps (full duplex), Jumbo frame support: 9K max. Chipset ID: Realtek RTL8111G, Industry standards: Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab. Compatibility with Windows 10 (32/64), 8, 8.1, 7, Vista, XP, 2000, ME, 98SE, Windows Server 2012, 2003, Linux Kernel 2.4.x and up operating system. LED indicators: four link and four activity. System and cable requirements: Available PCI Express x4 or higher (x8, x16) slot. Temperature: 0 - 55 deg C (operating), -40 - 70 deg C (storage), Humidity: 5 - 95% RH. Contains one PCIe gigabit network card. Meets CE, FCC and RoHS certifications and standards. Weight: 3.5 oz. Comes with 2 years warranty.
