| Brand | Waveshare |
| Package Dimensions | 6.81 x 5.31 x 2.39 cm; 9 g |
| Item model number | BC-2-CH UART To Ethernet Converter-W |
| Manufacturer | Waveshare |
| Colour | Transparent |
| Operating System | Mac |
| Are Batteries Included | No |
| Item Weight | 9 g |
| Guaranteed software updates until | unknown |
Overview
The 2-CH UART TO ETH provides an easy way to communicate between UART TTL and RJ45 Ethernet, allowing bi-directional transparent data transmission. It is easy to use, along with features like fast data rate, low power consumption, high stability, suits applications such as safety & security, IoT, and so on.
Features
(1). Embedded Ethernet MAC and PHY layers
(2). Bi-direction transparent data transmission between UART and Ethernet
(3). 10/100M, full-duplex/half-duplex auto-negotiation Ethernet interface, 802.3-compliant
(4). Auto-MDI/MDIX, detect and switch cable type automatically
(5). Supports DHCP auto-obtained IP and DNS domain access
(6). Network parameter configuration like chip operating mode, port, IP, via host computer software or UART command
(7). Four operating modes: TCP CLIENT, TCP SERVER, UDP CLIENT, UDP SERVER
(8). 2-CH UART concurrent operation, standalone transparent transmission for each channel
(9). Full-duplex or half-duplex UART communication, supports RS485 RX/TX auto switch
(10). Supports virtual serial port software (provided)
(11). KEEPALIVE mechanism support
(12). Comes with development resources and manual (examples for Pico/Raspberry Pi/Arduino/STM32)
Package Content
2-CH UART TO ETH x1
Note
Development Resources and Technical Support are provided, please feel free to contact us if you have any problem!
